| Number of stations | 43 |
|---|---|
| Standard of punch dies | IPT “B” |
| Maximum main pressure | 100 KN |
| Max. pre – pressure | 20 KN |
| Maximum filling depth | 18 mm |
| Maximum Tablet Thickness | 7 mm |
| Maximum tablet diameter | 18 mm |
| Max. speed of turret | 50 r.p/min |
| Maximum productivity | 258000 tablets/hour |
| Power of main motor | 11 Kw |
| Height of main motor without hopper | 1700 mm |
| Height of main motor with hopper | 1900 mm |
| Floor space occupied by the main machine | 1370 × 1170 mm |
| Weight of main machine | 3500 kg |
