| Labeling capacity (pes/min) | 40-200 pes/min (Related to the material and label size) |
|---|---|
| Labeling accuracy (mm) | +1.0mm |
| Label size | (L) 20-300mm (H) 10-180mm |
| Material size | (W) 20-200mm (H) 40-300mm |
| Roll inside (mm) | Φ 76mm |
| Roll outside diameter (mm) | MAX Φ 350mm |
| Machine size (mm) | (L) 2400* (W) 1000* (H) 1700(mm) |
| No | Name | Model | Qty | Brand |
|---|---|---|---|---|
| 1 | PLC | DVP-12SA211T | 1 | DELTA |
| 2 | PLC extender | DVP08SN11R | 1 | DELTA |
| 3 | Control panel | DOP-B07S411 | 1 | DELTA |
| 4 | communication cable | DOP-DVP-232 | 1 | |
| 5 | Frequency converter | VFD002L21A | 1 | DELTA |
| 6 | communication cable | DVP-VFD-485 | 1 | |
| 7 | DC24V | PMC-24V035W1AA | 1 | DELTA |
| 8 | Detect sensor with label | GS61/6.2 | 1 | Leuze |
| 9 | Detect sensor with object | FS-N18N | 1 | Keith |
| 10 | Reflective fiber | FU-35FA | 1 | Keith |
| 11 | transformer | JBK250/55V (Cu) | 1 | CNC |
| 12 | Power interface expansion module | DKM-PX01A-PO | 1 | Shanghai DongKong |
| 13 | stepper motor | 85BGYH4C | 1 | Shengzhen YAK |
| 14 | Motor driver | SMD2P4L-8A | 1 | Shengzhen YAKO |
| 15 | Rotary encoder | W38S6-100BM-G5-24F | 1 | DELTA |
| 16 | Power switch | ZB2-BE101C | 1 | Schneider |
| 17 | Emergency stop switch | ZB2-BE102C | 1 | Schneider |
| 18 | Air switch | DZ47-63 | 1 | China People |
| 19 | Conveyor servo motor | ECM-C20204RS | 1 | DELTA |
| 20 | Servo driver | ASD-B2-0421-B | 1 | DELTA |
| 21 | Transport motor gearbox | RV040/1 : 50 | 1 | Zhejiang JinLong |
| 22 | Press motor | JL632-4IE1 (0.18KW/1:30) | 1 | Zhejiang JinLong |
| 23 | Bottle tidy motor | 51K40GN-S/5GN20K | 2 | Zhejiang JinLong |
| 24 | Relay | LY2N-J (24V DC) | 1 | Omron |
| 25 | Fuse | RT18-2A | 5 | Shanghai Hu Gong |
| 26 | Alram | AD16-22SM | 1 | Ampute |
